SPECIFICATIONS
|
Nominal
cross-
sectional
area of
conductor
|
Nominal
diameter of
conductor
|
Nominal
thickness
of XLPE
insulation
|
Metallic
Screening
|
Nominal
diameter of
aluminium
wire
|
Nominal
thickness of
PVC sheath
|
Approximate
overall
diameter of
cable
|
Approximate weight of cable
|
|
Approximate
thickness of
copper tape
|
Copper
|
Aluminium
|
|
mm²
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
Kg/Km
|
Kg/Km
|
|
50
70
95
|
8.1
9.7
11.5
|
4.5
4.5
4.5
|
0.1
0.1
0.1
|
1.6
1.6
2.0
|
1.9
2.0
2.1
|
30
32
34
|
1401
1688
2111
|
1103
1257
1513
|
|
120
150
185
|
12.9
14.3
16.1
|
4.5
4.5
4.5
|
0.1
0.1
0.1
|
2.0
2.0
2.0
|
2.1
2.2
2.2
|
36
37
39
|
2412
2752
3188
|
1656
1824
2024
|
|
240
300
400
|
18.4
20.6
23.3
|
4.5
4.5
4.5
|
0.1
0.1
0.1
|
2.0
2.0
2.5
|
2.3
2.4
2.5
|
42
44
48
|
3875
4579
5709
|
2330
2640
3229
|
|
500
630
800
|
26.2
29.8
33.7
|
4.5
4.5
4.5
|
0.1
0.1
0.1
|
2.5
2.5
2.5
|
2.6
2.7
2.8
|
51
56
60
|
6849
8456
10362
|
3723
4400
5174
|
